Specifications
Kraft paper layers impregnated with thermosetting resin, faced with a decorative paper layer impregnated with aminoplastic resin, bonded under high pressure and heat. Produced to EN 438-3.
| Thickness | 0.9mm (tolerance ±0.10mm) |
| Sheet size | 2440 × 1220mm |
| Supplied as | Raw laminate sheet, not bonded to a substrate. Must be glued to a structural panel before use. |
| Density | > 1.35 g/cm³ (ISO 1183) |
| Resistance to surface wear | > 150 revolutions (EN 438-2.10) |
| Resistance to scratching | ≥ 2 smooth finish / ≥ 3 textured (EN 438-2.25) |
| Resistance to staining | 5 (groups 1–2), > 4 (group 3) (EN 438-2.26) |
| Lightfastness | > 4 grey scale (EN 438-2.27) |
| Resistance to dry heat (160°C) | > 3–4 rating (EN 438-2.16) |
| Resistance to wet heat (100°C) | > 3–4 rating (EN 438-2.18) |
| Internal / external use | Internal use |
| Suggested applications | Furniture panels, cabinetry, wall panelling, joinery (once glued to a structural panel) |
Test values from Filippi's HPL technical data sheet (EN 438 series). They describe the laminate material, not a fabricated composite panel.
